很多人对于滚珠丝杠异响产生了很大的疑问，今天导轨丝杠就来和大家介绍一下滚珠丝杠异响是因为什么原因。
Many people have great doubts about the abnormal noise of the ball screw. Today, the guide screw will introduce to you what causes the abnormal noise of the ball screw.
滚珠丝杠主要由丝杠、螺母、滚珠、循环器、密封圈、螺母座组成。因为又称为：滚珠丝杆、滚珠螺杆、丝母、丝杠等!滚珠丝杠和 螺母上加工有弧形旋转槽。当它们套装在一起时，便形成螺旋滚道，并在滚道内装滚珠。而滚珠则沿着丝杠滚道槽进行滚动。并经循环器作周而复始的循环运动。循环器两端还有一个密封圈，起挡滚珠、挡粉尘的作用，以防止源粉尘进入到螺母里面，粘附在滚珠上，对滚珠的运转带来一定的阻力。
Ball screw is mainly composed of screw, nut, ball, circulator, sealing ring and nut seat. Because it is also known as: ball screw, ball screw, screw nut, screw and so on! The ball screw and nut are processed with arc-shaped rotating groove. When they are set together, a spiral raceway is formed and balls are installed in the raceway. The ball rolls along the groove of the lead screw raceway. And through the circulator for the cycle of movement. There is also a seal ring at both ends of the circulator to block the ball and dust, so as to prevent the source dust from entering the nut and adhering to the ball, which will bring some resistance to the operation of the ball.

滚珠丝杠在装配前，如果没有异响，而在装配过程中发生异响 ， 原因肯定是装配时二端没有等高，二端不等高，往往我们肉眼是根本看不出来的，但是装机运行时，就会有异响，并且有卡顿的感觉。建议我们在装配的时候，不要一次性把一端拧紧后，再去拧另一端，先一端销拧一下，再拧另一端，这样反复，慢慢的多次拧紧。有异响的时候，请一定要 时间检测二端支撑座部分是否是等高的，或是有没有安装平整。
If there is no abnormal noise before the ball screw is assembled, but the abnormal noise occurs during the assembly process. The reason must be that the two ends are not equal in height and the two ends are unequal in height. We can't see them by naked eyes. However, when the ball screw is installed and running, there will be abnormal noise and a sense of jamming. It is suggested that we do not tighten one end at a time, and then screw the other end. First, screw one end pin, and then the other end, so that we can repeatedly and slowly tighten it many times. When there is abnormal noise, please be sure to check whether the two end support seat is of equal height or installed smoothly.
导轨丝杠
Guide screw
如果在装机前就感觉丝杆螺母滑动有异响，那就是预压调的太松了，简单来说，就是螺母刚珠与丝杆滚道槽间隙太大，导致来回运行时，发出“哗哗”的声音，但是这种声音是平稳的，不是尖锐刺耳的。如果是刺耳的话，可能是螺母进入其它异物，卡住刚珠导致。还有一种可能性是，丝杆微变形，导致直线度不好，也会在变形的地方产生异响。
If there is abnormal noise during the screw nut sliding before the installation, it is that the preloading adjustment is too loose. In short, the gap between the nut ball and the screw roller groove is too large, resulting in the sound of "Hua Hua Hua" when running back and forth, but the sound is stable, not sharp and harsh. If it is harsh, it may be caused by the nut entering into other foreign matters and jamming the rigid bead. Another possibility is that the screw rod is slightly deformed, resulting in poor straightness, and abnormal noise will be generated at the deformed place.
以上就是导轨丝杠对于滚珠丝杠为什么会异响的介绍，如果您有什么不同的意见或者建议可以联系我们，也可以在我们网站给我们留言http://www.jngongrun.com
If you have any different opinions or suggestions, you can contact us or leave us a message on our website http://www.jngongrun.com
