齿轮是互相啮合的有齿的机械零件，它在机械传动乃整个机械行业，日常生活中都有着很广泛的应用，齿轮的应用历史悠久，今也是机械行业中不可或缺的重要零件。接下来导轨丝杠厂家为您讲解一下齿轮齿条的分类及主要应用。

Gear is a mechanical part with teeth that mesh with each other. It is widely used in mechanical transmission and even in the whole mechanical industry and in daily life. The application of gear has a long history, and it is also an indispensable and important part in the mechanical industry. Next, the guide screw manufacturer will explain the classification and main application of gear and rack for you.

01

01

齿轮齿条工作原理：

Operating principle of gear and rack:

齿轮齿条工作原理是将齿轮的回转运动转变为齿条的往复直线运动，或将齿条的往复直线运动转变为齿轮的回转运动。

The working principle of gear and rack is to change the rotary motion of gear into the reciprocating linear motion of rack, or the reciprocating linear motion of rack into the rotary motion of gear.

02

02

齿轮分类：

Gear classification:

平行轴齿轮

Parallel shaft gear

正齿轮&齿条

Spur gear&rack

内齿轮&斜齿齿轮

Internal gear&helical gear

斜齿齿条&人字齿轮

Helical rack&herringbone gear

交错轴齿轮

Staggered shaft gear

直齿锥齿轮

Straight bevel gear

弧齿锥齿轮&零度锥齿轮

Spiral bevel gear&zero degree bevel gear

交错轴齿轮

Staggered shaft gear

圆柱蜗杆副&交错轴斜齿齿轮

Cylindrical worm pair&staggered helical gear

其他特殊齿轮

Other special gears

鼓型蜗杆副&准双曲面齿轮

Drum worm pair&hypoid gear

面齿轮

Face gear

03

03

齿轮齿条机构：

Rack and pinion mechanism:

齿轮齿条机构是由齿轮和齿条构成的，齿轮前面我们有很详细的讲解。齿条分直齿齿条和斜齿齿条，齿条的齿廓为直线而非渐开线，相当于分度圆半径为无穷大圆柱齿轮。

The rack and pinion mechanism is composed of gear and rack. We have explained the gear in detail before. The rack is divided into straight rack and helical rack. The tooth profile of the rack is straight rather than involute, which is equivalent to a cylindrical gear with an infinite radius of indexing circle.

齿条的主要特点

Main features of rack

由于齿条齿廓为直线，所以齿廓上各点具有相同的压力角，且等于齿廓的倾斜角，此角称为齿形角，标准值为20°。

Because the rack tooth profile is straight, each point on the tooth profile has the same pressure angle and is equal to the inclination angle of the tooth profile. This angle is called the tooth profile angle, and the standard value is 20 °.

与齿顶线平行的任一条直线上具有相同的齿距和模数。

Any straight line parallel to the tooth top line has the same tooth pitch and modulus.

与齿顶线平行且齿厚等于齿槽宽的直线称为分度线（中线），它是计算齿条尺寸的基准线。

The straight line parallel to the tooth top line and the tooth thickness equal to the width of the tooth slot is called the indexing line (center line), which is the reference line for calculating the size of the rack.

04

04

齿轮齿条传动的应用范围：

Application range of rack and pinion drive:

1、适用于快速、精准的定位机构

1. Suitable for fast and accurate positioning mechanism

2、适用于重负荷、高精度、高刚性、高速度和长行程的CNC机床、加工、切割机械、焊接机械等

2. Suitable for CNC machine tools, machining centers, cutting machines, welding machines, etc. with heavy load, high precision, high rigidity, high speed and long stroke

3、适用于工厂自动化快速移栽机械、工业机器人手臂抓取机构等

3. It is applicable to factory automatic rapid transplanting machinery, industrial robot arm grabbing mechanism, etc

齿轮齿条的分类及主要应用相关内容就讲解到这里了，您对此有怎样的疑惑或者需求，欢迎来我们网站http://www.jngongrun.com咨询！

The classification and main application of gear and rack will be explained here. What doubts or needs do you have about this? Welcome to our website http://www.jngongrun.com consulting service
