在现在自动化设备越来越普及的时代，直线导轨的使用会越来越多，而直线导轨运用常见问题也会越来越多，问题都是用来解决的。导轨丝杠厂家就跟朋友们来做一下直线导轨运用常见问题的汇总。

In the era of more and more popular automation equipment, the use of linear guide rail will be more and more, and the common problems in the use of linear guide rail will also be more and more, problems are used to solve. The guide screw manufacturer will work with friends to summarize the common problems in the use of linear guide.

1、运作一段时间之后，可能会发现直线导轨的轨迹有印压痕，而且滑块钢珠开裂，这是什么原因？

1. After operating for a period of time, it may be found that the track of the linear guide rail has imprints, and the steel ball of the slider is cracked. What is the reason?

一般是因为负荷过大，钢珠离开轨迹，造成钢珠开裂导致轨迹持续损害。这种情况可以考虑拆换大一级的滑块，比如20的，更换成25的，或者增加滑块数量，降低外部荷载，改变安裝办法下降一侧承受能力情况。倘若来源于光滑的原因，可以考虑选用另一种润滑油，增加润滑度，减小润化间距。须经常查看有没有脏东西进到滑轨，若有脏东西进入就需要改进密封性零配件，或者增加防尘配件。

Generally, the steel ball leaves the track due to excessive load, causing the steel ball to crack and causing continuous damage to the track. In this case, it can be considered to replace the sliding block of a larger level, such as 20, with 25, or increase the number of sliding blocks, reduce the external load, and change the installation method to reduce the bearing capacity of one side. If it comes from the reason of smoothness, another lubricating oil can be considered to increase the lubricating degree and reduce the lubricating distance. Always check whether there is dirt entering the slide rail. If there is dirt entering, it is necessary to improve the sealing parts or add dust prevention parts.

2、滑块运作一段时间后会出現钢珠掉出来的情况是为什么？

2. Why does the steel ball fall out after the sliding block operates for a period of time?

铁销从珠沟掉下来导致钢珠损害使用期结束，使钢件表面有疲倦与负荷过重的情况，或许是由于太多负荷、安裝不正确或只要一侧承受力距，这些情况，都有或许导致钢珠脱落。

The iron pin falls from the bead groove, causing damage to the steel ball and ending the service life, making the steel surface tired and overloaded, perhaps due to too much load, incorrect installation, or as long as one side bears the force distance, which may cause the steel ball to fall off.

3、在滑块行走一段时间后，发现轴承端盖与端防污有形变或裂开情况？

3. After the sliding block moves for a period of time, it is found that the bearing end cap and the end anti fouling are deformed or cracked?

安装办法的有误，会让滑块与轨道间仅有一侧承受力，也或许是遭到外力损害而导致轴承端盖与端防污的形变或裂开。滑块内部较差的，能够变化防污体系，更换别的光滑油脂，加上光滑油量，下降润化時间距离。安裝时要注意安裝视角的难点，产品装备的提升，需要由的技能工程师来安裝，防止损害直线导轨滑块。

If the installation method is wrong, only one side between the sliding block and the rail will bear the force, or it may be damaged by external forces, resulting in deformation or cracking of the bearing end cap and end anti fouling. If the interior of the slider is poor, the anti fouling system can be changed, other smooth grease can be replaced, and with the amount of smooth oil, the lubrication time and distance can be reduced. Attention shall be paid to the difficulties of installation perspective during installation. The improvement of product equipment shall be installed by professional skilled engineers to prevent damage to linear guide sliders.

以上关于直线导轨使用常见问题点反馈汇总，仅仅日常工作中遇到的常见的一部分问题，欢迎朋友们补充，也可联系小编http://www.jngongrun.com，分享交流！

The feedback summary of the above common problems about the use of linear guide rail is only a part of the common problems encountered in daily work. You are welcome to add, or contact the editor http://www.jngongrun.com , share and exchange!
